Ultrasound Image Segmentation of Histotripsy Ablation Using DeepLabV3 with Combined Dice-Focal Loss

This repository contains the code and resources for the research project on segmenting histotripsy ablation zones in ultrasound images using DeepLabV3 (and other experimental models) with a combined Dice-Focal loss function.

Authors: Shreyans Jain, Soham Gaonkar, Aditya Borate, Mihir Agarwal, Muskan Singh, Prof. Kenneth B. Bader, Prof. Himanshu Shekhar
Contact: [email protected], [email protected], [email protected], [email protected], [email protected]

---

Table of Contents

1. Introduction
2. Motivation
3. Methodology
   • Model Architecture
   • Loss Function
4. Repository Structure
5. Experimental Setup
   • Dataset
6. Results
7. Challenges Faced
8. Future Work
9. Citation
10. Acknowledgments

---

1. Introduction

Histotripsy is an emerging non-invasive ultrasound-based therapy that uses high-amplitude focused ultrasound pulses to mechanically ablate tissue without heat or incisions. Real-time monitoring and assessment of the ablated region are crucial for effective treatment. This project explores deep learning-based segmentation approaches, primarily focusing on DeepLabV3 with a combined Dice-Focal loss, to accurately identify and segment histotripsy-induced ablation zones from B-mode ultrasound images.

2. Motivation

• Current imaging modalities like MRI/CT for monitoring histotripsy ablation are slow, costly, and not ideal for real-time feedback.
• Ultrasound imaging is a readily available, cost-effective, and real-time alternative.
• Accurate segmentation of the ablated region in ultrasound images is challenging due to low contrast, speckle noise, sparse bubble regions (especially in early-pulse frames), and variability in bubble cloud appearance.
• Our Goal: To enable real-time assessment of histotripsy ablation using ultrasound imaging alone by developing robust segmentation models.

3. Methodology

The overall workflow involves: Data Acquisition → Data Annotation → Preprocessing & Augmentation → Supervised Learning → Evaluation.

Model Architecture

• The primary model discussed in our poster is DeepLabV3 with a ResNet101 backbone, trained from scratch in a fully supervised setting (code_files/model/deeplabv3_torchvision.py, code_files/model/deeplabv3p.py).
• DeepLabV3 utilizes atrous (dilated) convolutions and Atrous Spatial Pyramid Pooling (ASPP) to capture multi-scale context effectively.
• The repository also includes implementations or experiments with other architectures such as U-Net++ (unetpp.py), FPN (fpn.py), Mask R-CNN (maskrcnn.py), and a ResNet18-based CNN (resnet18cnn.py), found in the code_files/model/ directory.

Loss Function

To handle class imbalance and enhance boundary precision, we primarily employ a combined Dice + Focal Loss (code_files/loss/dice_focal.py): L_Total = λ_Dice * L_Dice + λ_Focal * L_Focal

• Dice Loss: Maximizes overlap in sparse masks (code_files/loss/dice.py). DiceLoss(y, p̂) = 1 - (2p̂y + ε) / (p̂ + y + ε)
• Focal Loss: Emphasizes hard-to-classify pixels. FocalLoss(p_t) = -α_t (1 - p_t)^γ log(p_t)
• Other experimental loss functions like Asymmetric Tversky Loss (asymmetric_tversky.py) and a Dice-Focal variant with pulse prior (dice_focal_pulse_prior.py) are also available in the code_files/loss/ directory.

4. Repository Structure

adi776borate-bubblesegmentation/
├── README.md
├── code_files/                     # Main Python scripts and modules
│   ├── config.py
│   ├── dataloader.py
│   ├── latest_copy.ipynb
│   ├── metric.py
│   ├── run_all.py
│   ├── test.py
│   ├── train.py
│   ├── utils.py
│   ├── zcleanup.py
│   ├── loss/
│   │   ├── __init__.py
│   │   ├── asymmetric_tversky.py
│   │   ├── dice.py
│   │   ├── dice_focal.py
│   │   └── dice_focal_pulse_prior.py
│   └── model/                      # Model architecture implementations
│       ├── __init__.py
│       ├── deeplabv3_torchvision.py
│       ├── deeplabv3p.py
│       ├── fpn.py
│       ├── maskrcnn.py
│       ├── resnet18cnn.py
│       └── unetpp.py
├── Data/                           # Dataset
│   ├── Label_2/
│   ├── Label_Test_2023April7/
│   ├── US_2/
│   └── US_Test_2023April7/
└── dump/                           # Additional/older Jupyter notebooks
    ├── bubblesegment.ipynb
    └── Only_testing.ipynb

5. Experimental Setup

Dataset

• B-mode ultrasound images were collected during histotripsy experiments in collaboration with UChicago Radiology.
• Experiments: Agarose phantoms and ex vivo porcine kidneys.
• Ultrasound parameters: 1 MHz transducer, 35 MPa, 20 µs pulses @ 50 Hz.
• Ground truth: Annotated using co-registered digital images.
• Dataset split: 6 datasets → 880 train / 400 test / holdout set.
  • The Data/ directory shows an example structure:
    • Training Images: Data/US_2/
    • Training Labels: Data/Label_2/
    • Test Images: Data/US_Test_2023April7/
    • Test Labels: Data/Label_Test_2023April7/
• Unlabelled data for unsupervised exploration was provided by Vishwas Trivedi (PhD student, IIT Gandhinagar).
• Data Augmentation & Oversampling: Techniques were applied to increase model robustness, especially for early-pulse frames. Logic for this is within code_files/dataloader.py.

6. Results

Our proposed method (DeepLabV3 with Dice-Focal Loss) demonstrates significant improvements.

• Quantitative Metrics:

  Metric	Our Results	Prior SOTA Results
  Global Accuracy	0.97525	0.95555
  Mean Accuracy	0.90524	0.69524
  Mean IoU	0.82537	0.76461
  Weighted IoU	0.93525	0.91648

  (Evaluation metrics are computed using code_files/metric.py)

• Qualitative Results:

7. Challenges Faced

• Ground truth annotation variability.
• Difficulty in segmenting sparse bubble regions from initial pulses.
• Scarcity of annotated histotripsy data.

8. Future Work

• Improve early-pulse segmentation (e.g., using curriculum learning).
• Integrate attention mechanisms and adaptive loss strategies.
• Explore unsupervised/semi-supervised learning with limited labels.

9. Citation

• Miao K, Basterrechea KF, Hernandez SL, Ahmed OS, Patel MV, Bader KB. Development of Convolutional Neural Network to Segment Ultrasound Images of Histotripsy Ablation. IEEE Trans Biomed Eng. 2024 Jun;71(6):1789-1797. doi: 10.1109/TBME.2024.3352538. Epub 2024 May 20. PMID: 38198256.
• Chen, L., Papandreou, G., Schroff, F., & Adam, H. (2017). Rethinking Atrous Convolution for Semantic Image Segmentation. ArXiv. https://arxiv.org/abs/1706.05587

10. Acknowledgments

• This work was conducted at the MUSE LAB, IIT Gandhinagar.
• We thank UChicago Radiology for collaboration and experimental data.
• We acknowledge Vishwas Trivedi (IIT Gandhinagar) for unlabelled ultrasound data.
